Compact and lightweight, the AUXSOL ASN series is the perfect choice for residential installations. The ASN series boasts excellent durability, an ultra-long lifespan under modern industrial standards, and an IP66 protection rating, suitable for indoor and outdoor environments.
High Efficiency
Max. 18A single string current, compatible with 210 large modules
Supports oversizing 1.5x DC/AC
40V low start-up voltage enables early startup and more energy generation
Smart
Ultra-wide grid voltage design with automatic voltage regulation technology ensures uninterrupted operation even under unstable grid conditions
User-Friendly
Silent design (＜35dB)
Safe and Reliable
IP66 protection rating, adaptable to harsh operating environments
Intelligent AFCI reduces fire risk
Economical and Cost-Saving
Compact and lightweight design for easy installation and maintenance
No power derating at 45°C, more reliable with more yield
| Technical Data | ASN-3SL | ASN-3.3SL |
|---|---|---|
|
Start-up voltage |
40V |
|
|
MPPT voltage range |
40-520V |
|
|
Max. input current |
18A |
|
|
MPPT number |
1 |
|
|
Max. input strings |
1 |
|
|
Max. output power |
3.3 kVA |
|
|
Rated grid output current |
13.6A |
15A |
|
Max. output current |
15A |
15A |
